CV Lamp
An exploration with 3D fabrication and hardware to make interactive home devices.
More than a lamp
The brain
A webcam connected to a Raspberry Pi 4 captures a live feed of the user’s hand. Using OpenCV and Google’s MediaPipe framework, the system maps 21 landmark points across the hand in real time. A Python script checks whether those points match a predefined gesture, like a peace sign.
Receiver
Once a gesture is recognized, the Raspberry Pi sends an HTTP request over Wi-Fi to an ESP32 microcontroller. The request carries JSON data specifying a lighting mode, formatted to match the API used by WLED, an open-source LED control firmware.
LED Output
The ESP32, running WLED, receives the request and applies the corresponding effect to a WS2812B addressable LED strip. The result is a gesture-controlled lighting system where a hand movement translates to a visible change in the LEDs within seconds.
The project consists of 2 pieces of hardware that makes this effect happen with some help of libraries inside the python script. How these micro-controllers interact with each other is completely done over the network.
Designing a lamp shade
Every lamp needs a shade and base, so I designed and 3D printed custom housing using Fusion360. The modeling skills came from coursework in Bret Ratner’s Physical Computing class in the makerspace, where I first started working with fabrication. The overall aesthetic of the lamp is heavily inspired by Dieter Rams’ functional minimalism and Teenage Engineering’s playful industrial design.
